What is the proper way to set these up for the first time?

Set up your NVGs to focus out to distance. Attach Tarsier Eclipse to NVGs Slowly dial your Tarsier Eclipse. Once the image in your NVGs starts to lose light, back off slightly from the Tarsier (opening it back up a tiny bit). This should be the perfect setting for the ambient conditions you're in. Here is a step-by-step video of another way that is equally as good: https://youtu.be/9B25vCK7aA0

MATBOCK Tarsier Eclipse™

Name: Tarsier Eclipse ™ Kit
Brand: MATBOCK
SKU: 880021-NAVAIR
Price: 530.0 USD
Availability: InStock

MADE IN THE USA

TARSIER ECLIPSE™

Own the Night with the most advanced night vision accessory on the market

Tarsier Eclipse Engaged vs not

$530.00

Please reach out to orders@matbock.com if you have any questions about lead times or the product.

Department of Commerce Controlled Item

International shipping requires approval. If you have questions, please email sales@matbock.com and we will help you right away.

The Tarsier Eclipse ™ is the most advanced Night Vision Goggle (NVG) accessory on the market, allowing the operator to see objects from 3" to infinity at the same time and without loss of clarity. It incorporates a smooth action and a high-performance optical iris that can quickly be adjusted depending on the amount of ambient light. Additionally, the Tarsier Eclipse ™ offers a high-quality Corning Glass sacrificial lens that can quickly be replaced without tools. The sacrificial lens serves as a critical piece of protection for your NVG lenses, shielding them from dust, dirt, or scratching that may cause expensive repairs and potential downtime.

Included in a Tarsier Eclipse kit are 2 x Tarsier Eclipse ™ (880021-NAVAIR or 880021- GROUND), an additional Sacrificial Lens, a cleaning kit, and 2 lanyards with swivel hook attachment.

Provides the ability to see objects at all distances without adjusting the focus on Night Vision Goggles.
Infinitely variable from open to close to allow the optimal amount of light into the NVGs and maintain auto-focus capability.
Clear front sacrificial lens to protect the lens of NVGs and prevent dust and debris from entering the apparatus.
Rapid adaptation to ambient light by turning the adjustment ring, and opening or closing the iris.
Easy and secure attachment to end of NVGs.
50lb test lanyard

The Tarsier Eclipse Kits™ will fit the following models:

PN# 880021-NAVAIR (fits 37mm Outside Diameter): AN/PVS6 || AN/PVS-7 || AN/PVS-7B/D || ANVIS-9 || AN/PVS-14 || NEPVS-14 || AN/PVS-23 (F5050YG) || DTNVG || DTNVS || BNVD 1531 || AN/PVS-31D || RNVG

PN# 880021-GROUND (fits 34mm Outside Diameter): AN/PVS-15 || AN/PVS-18 || AN/PVS-31A || BNVD || MUM-14 || GPNVG

NSN: 6650-01-718-0894

Patent Number: 7969673

Licensed technology from Phokus Research Group
www.phokusresearch.com

Specs:

Material: Harden Rubber
Total Weight: 1.1oz (31 grams)
Dimensions: 1" x 2" x 2"
37mm Outer diameter needs Part Number: 880021-1 or 880021-NAVAIR
33mm Outer diameter needs Part Number: 880021-2 or 880021-GROUND

Size

NAVAIR Kit 37MM (1.446")

GROUND Kit 34MM (1.346")

[{"id":44231532904680,"title":"NAVAIR Kit 37MM (1.446\")","option1":"NAVAIR Kit 37MM (1.446\")","option2":null,"option3":null,"sku":"880021-NAVAIR","requires_shipping":true,"taxable":true,"featured_image":{"id":29848354062512,"product_id":6718684463280,"position":3,"created_at":"2021-09-13T11:50:09-04:00","updated_at":"2023-11-30T10:21:08-05:00","alt":null,"width":600,"height":600,"src":"\/\/www.matbock.com\/cdn\/shop\/products\/Tarsier-4.png?v=1701357668","variant_ids":[44231532904680]},"available":true,"name":"Tarsier Eclipse ™ Kit - NAVAIR Kit 37MM (1.446\")","public_title":"NAVAIR Kit 37MM (1.446\")","options":["NAVAIR Kit 37MM (1.446\")"],"price":53000,"weight":454,"compare_at_price":null,"inventory_quantity":-119,"inventory_management":null,"inventory_policy":"deny","barcode":"","featured_media":{"alt":null,"id":22130424545456,"position":3,"preview_image":{"aspect_ratio":1.0,"height":600,"width":600,"src":"\/\/www.matbock.com\/cdn\/shop\/products\/Tarsier-4.png?v=1701357668"}},"requires_selling_plan":false,"selling_plan_allocations":[]},{"id":44231532970216,"title":"GROUND Kit 34MM (1.346\")","option1":"GROUND Kit 34MM (1.346\")","option2":null,"option3":null,"sku":"880021-GROUND","requires_shipping":true,"taxable":true,"featured_image":{"id":28991976276144,"product_id":6718684463280,"position":1,"created_at":"2021-06-15T13:25:17-04:00","updated_at":"2021-09-20T14:17:28-04:00","alt":null,"width":600,"height":600,"src":"\/\/www.matbock.com\/cdn\/shop\/products\/tarsier-2_bd589719-3dfa-46ff-8376-3f150c576707.png?v=1632161848","variant_ids":[44231532970216]},"available":true,"name":"Tarsier Eclipse ™ Kit - GROUND Kit 34MM (1.346\")","public_title":"GROUND Kit 34MM (1.346\")","options":["GROUND Kit 34MM (1.346\")"],"price":53000,"weight":454,"compare_at_price":null,"inventory_quantity":-105,"inventory_management":null,"inventory_policy":"deny","barcode":"","featured_media":{"alt":null,"id":21254649839792,"position":1,"preview_image":{"aspect_ratio":1.0,"height":600,"width":600,"src":"\/\/www.matbock.com\/cdn\/shop\/products\/tarsier-2_bd589719-3dfa-46ff-8376-3f150c576707.png?v=1632161848"}},"requires_selling_plan":false,"selling_plan_allocations":[]}]

Kit VS. Single

Included in a Tarsier Eclipse kit are 2 x Tarsier Eclipse ™ (880021-NAVAIR or 880021- GROUND ), an additional Sacrificial Lens, a cleaning kit, and 2 lanyards with swivel hook attachment.

$250.00

MATBOCK Products are handmade to order, so lead times can vary.

Please contact orders@matbock.com with questions on current production lead times.

Department of Commerce Controlled Item

International shipping requires approval. If you have questions, please email sales@matbock.com and we will help you right away.

The Tarsier Eclipse ™ is the most advanced Night Vision Goggle (NVG) accessory on the market, allowing the operator to see objects from 3" to infinity at the same time and without loss of clarity. It incorporates a smooth action and a high-performance optical iris that can quickly be adjusted depending on the amount of ambient light.

Additionally, the Tarsier Eclipse ™ offers a high-quality Corning Glass sacrificial lens that can quickly be replaced without tools. The sacrificial lens serves as a critical piece of protection for your NVG lenses, shielding them from dust, dirt, or scratching that may cause expensive repairs and potential downtime.

Provides the ability to see objects at all distances without adjusting the focus on Night Vision Goggles.
Infinitely variable from open to close to allow the optimal amount of light into the NVGs and maintain auto-focus capability.
Clear front sacrificial lens to protect the lens of NVGs and prevent dust and debris from entering the apparatus.
Rapid adaptation to ambient light by turning the adjustment ring, and opening or closing the iris.
Easy and secure attachment to end of NVGs with a 50lb test lanyard.

The Tarsier Eclipse ™; (sold per tube) will fit the following models:

**Please note, if you have dual NVG's, you will need to add 2 Tarsier Eclipses to your cart OR purchase a Tarsier Eclipse Kit which includes 2 Tarsiers, an extra sacrificial lens and a cleaning kit for $530

PN# 880021-1 (fits 37mm Outer Diameter): AN/PVS6 || AN/PVS-7 || AN/PVS-7B/D || ANVIS-9 || AN/PVS-14 || NEPVS-14 || AN/PVS-23 (F5050YG) || DTNVG || DTNVS || BNVD 1531 || PVS-31D || RNVG

PN# 880021-2 (fits 34mm Outer Diameter): AN/PVS-15 || AN/PVS-18 || AN/PVS-31A || BNVD || MUM-14 || GPNVG

NSN: 6650-66-167-6919

Patent Number: 7969673

Licensed technology from Phokus Research Group
www.phokusresearch.com

Specs:

Material: Harden Rubber
Total Weight: 1.1oz (31 grams)
Dimensions: 1" x 2" x 2"
37mm Outer diameter needs Part Number: 880021-1 or 880021-NAVAIR
33mm Outer diameter needs Part Number: 880021-2 or 880021-GROUND

Size

37MM (1.446")

34MM (1.346")

[{"id":44231501054184,"title":"37MM (1.446\")","option1":"37MM (1.446\")","option2":null,"option3":null,"sku":"880021-1","requires_shipping":true,"taxable":true,"featured_image":{"id":29848292655280,"product_id":146182939,"position":4,"created_at":"2021-09-13T11:45:03-04:00","updated_at":"2023-11-30T10:21:39-05:00","alt":null,"width":600,"height":600,"src":"\/\/www.matbock.com\/cdn\/shop\/products\/TARSIER_MONO1600x600.png?v=1701357699","variant_ids":[44231501054184]},"available":true,"name":"Tarsier Eclipse ™ - Single - 37MM (1.446\")","public_title":"37MM (1.446\")","options":["37MM (1.446\")"],"price":25000,"weight":454,"compare_at_price":null,"inventory_quantity":-176,"inventory_management":null,"inventory_policy":"deny","barcode":"","featured_media":{"alt":null,"id":22130362417328,"position":4,"preview_image":{"aspect_ratio":1.0,"height":600,"width":600,"src":"\/\/www.matbock.com\/cdn\/shop\/products\/TARSIER_MONO1600x600.png?v=1701357699"}},"requires_selling_plan":false,"selling_plan_allocations":[]},{"id":44231501086952,"title":"34MM (1.346\")","option1":"34MM (1.346\")","option2":null,"option3":null,"sku":"880021-2","requires_shipping":true,"taxable":true,"featured_image":{"id":29781975826608,"product_id":146182939,"position":9,"created_at":"2021-09-07T20:56:27-04:00","updated_at":"2023-11-30T10:21:39-05:00","alt":null,"width":600,"height":600,"src":"\/\/www.matbock.com\/cdn\/shop\/products\/Tarsier-4_bino_Concept_2.jpg?v=1701357699","variant_ids":[44231501086952]},"available":true,"name":"Tarsier Eclipse ™ - Single - 34MM (1.346\")","public_title":"34MM (1.346\")","options":["34MM (1.346\")"],"price":25000,"weight":454,"compare_at_price":null,"inventory_quantity":-88,"inventory_management":null,"inventory_policy":"deny","barcode":"","featured_media":{"alt":null,"id":22062954610864,"position":9,"preview_image":{"aspect_ratio":1.0,"height":600,"width":600,"src":"\/\/www.matbock.com\/cdn\/shop\/products\/Tarsier-4_bino_Concept_2.jpg?v=1701357699"}},"requires_selling_plan":false,"selling_plan_allocations":[]}]

Product Collection

Sort

Tarsier Eclipse ™ Kit

$530.00

Tarsier Eclipse ™ - Single

$250.00

Tarsier Eclipse ™ Sacrificial Lens

$25.00

Tarsier Eclipse ™ Cleaning Kit

$35.00

TARSIER ECLIPSE™ FAQs

This is your 50lb test lanyard and in the packaging there should also be a swivel so you can attach your Tarsier Eclipse unit to your NVG.

We pride ourselves in not sourcing anything from China and these are all made in the USA.

The Tarsier Eclipse was designed so that you can take it apart without any tools. You can simply pull the outer rubber housing off the Tarsier and slowly stretch it back out and if you have a cleaning kit, you can also apply a little lube. Here is a video to help: https://youtu.be/qRv_43L405c

Set up your NVGs to focus out to distance.
Attach Tarsier Eclipse to NVGs
Slowly dial your Tarsier Eclipse. Once the image in your NVGs starts to lose light, back off slightly from the Tarsier (opening it back up a tiny bit). This should be the perfect setting for the ambient conditions you're in.

Here is a step-by-step video of another way that is equally as good: https://youtu.be/9B25vCK7aA0

For best results, measure your the outer diameter of your NVG front focal lens, but here is a list of the ones that we have found.

37mm Outside Diameter fits these: AN/PVS6 || AN/PVS-7 || AN/PVS-7B/D || ANVIS-9 || AN/PVS-14 || NEPVS-14 || AN/PVS-23 (F5050YG) || DTNVG || DTNVS || BNVD 1531 || AN/PVS-31D || RNVG

34mm Outside Diameter fits these: AN/PVS-15 || AN/PVS-18 || AN/PVS-31A || BNVD || MUM-14 || GPNVG

Own the night

Seeing near and far without loss of clarity!
